G31F 1493NP 4L

The G31F 1493NP 4L is an actively cooled embedded industrial network appliance based on the Intel Celeron J Series platform. It features 4 × 2.5GbE RJ45 ports, dual DDR4 SO-DIMM memory slots, M.2 high-speed storage, SATA 3.0, M.2 Key-B, M.2 Key-E, SIM card support, and serial expansion. With its compact metal chassis and intelligent chassis fan, it provides stable low-temperature operation under continuous workloads, making it suitable for cybersecurity appliances, IoT edge gateways, industrial automation, embedded terminals, and edge computing deployments.

Place an order

The G31F 1493NP 4L is an actively cooled embedded industrial network appliance based on the Intel Celeron J Series platform. It integrates 4 × 2.5GbE RJ45 ports, dual DDR4 SO-DIMM memory slots, M.2 high-speed storage, SATA 3.0, M.2 Key-B, M.2 Key-E, SIM card support, and serial expansion. With a compact metal chassis and intelligent chassis fan, it is designed to maintain stable operating temperatures under continuous workloads.

Key Features

Intel Celeron J Series Platform: Provides a low-power embedded computing foundation for reliable long-term operation.
4 × 2.5GbE RJ45 Ports: Built with 4 Intel I226V Ethernet controllers for high-speed, low-latency multi-port networking.
Dual DDR4 Memory Slots: Supports 2 × DDR4 SO-DIMM, up to 32GB capacity and up to 3200 MT/s frequency.
M.2 High-Speed Storage: Includes 1 × M.2 Key-M 2280 slot for high-speed SSD storage and fast system performance.
SATA 3.0 Expansion: Provides 1 × SATA 3.0 interface for SATA SSD or HDD expansion.
Wireless Expansion Ready: Supports M.2 Key-B 3052, M.2 Key-E 2230, and SIM card slot for 4G/5G, Wi-Fi, or Bluetooth modules.
Industrial I/O: Provides RJ45 COM RS232, JCOM RS232/RS485, JGPIO, and front panel connector for industrial peripherals.
Active Cooling Design: Equipped with an intelligent chassis fan for stable low-temperature operation under continuous workloads.
Compact and Reliable Build: Metal chassis design with a system size of approximately 178 × 126 × 56 mm.

Core Specifications

Model: G31F 1493NP 4L
Processor Platform: Intel Celeron Processor J Series
Socket: FCBGA1493
Memory: 2 × DDR4 SO-DIMM, up to 32GB, up to 3200 MT/s
Network: 4 × 2.5GbE RJ45, Intel I226V controllers
Storage: 1 × SATA 3.0, 1 × M.2 Key-M 2280
Expansion: 1 × M.2 Key-B 3052, 1 × M.2 Key-E 2230
Display: 1 × DP, 1 × HD
USB: 1 × USB-A 3.0, 3 × USB-A 2.0
Serial Port: 1 × RJ45 COM RS232, 1 × JCOM RS232 or RS485
Other Interfaces: 1 × SIM card slot, 1 × JGPIO, 1 × F_Panel, 2 × reserved antenna holes
Cooling Method: Active cooling with 1 × smart chassis fan
Power Input: DC 12V 4A or higher
Chassis Size: 178 × 126 × 56 mm
Device Weight: Approx. 1.25 KG; package weight approx. 1.95 KG including accessories
Operating Temperature: 0°C to 50°C
Operating Humidity: 5% to 90% relative humidity, non-condensing
