G30S 1493NP 4L

The G30S 1493NP 4L is a compact fanless embedded industrial network computer based on the Intel Celeron J Series platform. It features 4 × 2.5GbE RJ45 ports, dual DDR4 SO-DIMM memory slots, M.2 high-speed storage, SATA 3.0, M.2 Key-B, M.2 Key-E, SIM card support, and serial expansion. With its compact metal chassis and passive cooling design, it provides a stable, low-power, and quiet platform for cybersecurity appliances, IoT edge gateways, industrial automation, embedded terminals, and space-constrained edge computing deployments.

Place an order

The G30S 1493NP 4L is a compact fanless embedded industrial network computer based on the Intel Celeron J Series platform. It integrates 4 × 2.5GbE RJ45 ports, dual DDR4 SO-DIMM memory slots, M.2 high-speed storage, SATA 3.0, M.2 Key-B, M.2 Key-E, SIM card support, and serial expansion. With a compact metal chassis and passive cooling design, it is built for low-power, quiet, and stable long-term operation in industrial network and edge computing environments.

Key Features

Intel Celeron J Series Platform: Provides a low-power embedded computing foundation for reliable 24/7 operation.
4 × 2.5GbE RJ45 Ports: Built with 4 Intel I226V Ethernet controllers for high-speed, low-latency multi-port networking.
Dual DDR4 Memory Slots: Supports 2 × DDR4 SO-DIMM, up to 32GB capacity and up to 3200 MT/s frequency.
M.2 High-Speed Storage: Includes 1 × M.2 Key-M 2280 slot for high-speed SSD storage and fast system performance.
SATA 3.0 Expansion: Provides 1 × SATA 3.0 interface for SATA SSD or HDD expansion.
Wireless Expansion Ready: Supports M.2 Key-B 3052, M.2 Key-E 2230, and SIM card slot for 4G/5G, Wi-Fi, or Bluetooth modules.
Industrial I/O: Provides RJ45 COM RS232, JCOM RS232/RS485, JGPIO, and front panel connector for industrial peripherals.
Fanless Passive Cooling: The metal chassis and passive cooling structure reduce noise, dust intake, and maintenance requirements.
Compact Chassis: The system measures approximately 136 × 126 × 40 mm, making it suitable for space-limited installations.

Core Specifications

Model: G30S 1493NP 4L
Processor Platform: Intel Celeron Processor J Series
Socket: FCBGA1493
Memory: 2 × DDR4 SO-DIMM, up to 32GB, up to 3200 MT/s
Network: 4 × 2.5GbE RJ45, Intel I226V controllers
Storage: 1 × SATA 3.0, 1 × M.2 Key-M 2280
Expansion: 1 × M.2 Key-B 3052, 1 × M.2 Key-E 2230
Display: 1 × DP, 1 × HD
USB: 1 × USB-A 3.0, 3 × USB-A 2.0
Serial Port: 1 × RJ45 COM RS232, 1 × JCOM RS232 or RS485
Other Interfaces: 1 × SIM card slot, 1 × JGPIO, 1 × F_Panel, 2 × reserved antenna holes
Cooling Method: Passive cooling, fanless design, airflow recommended
Power Input: DC 12V 4A or higher
Chassis Size: 136 × 126 × 40 mm
Device Weight: Approx. 0.65 KG; package weight approx. 1.25 KG including accessories
Operating Temperature: 0°C to 50°C
Operating Humidity: 5% to 90% relative humidity, non-condensing
