G31F 1140N4L

The G31F-1140N4L is a high-performance industrial network appliance powered by the AMD Ryzen Embedded R2314 processor.  It integrates 4 × 2.5GbE RJ45 ports, dual SIM slots, DDR4 SO-DIMM memory, SATA and M.2 storage,  plus mPCIe and M.2 Key-B expansion. With a compact metal chassis and intelligent active cooling,  it is designed for edge computing, cybersecurity appliances, industrial gateways, virtualization platforms,  and industrial automation applications.

Key Features

• AMD Ryzen Embedded R2314 Platform: Delivers strong embedded computing performance for industrial and edge workloads.

• 4 × 2.5GbE RJ45 Ports: Built with 4 Intel I226V Ethernet controllers for high-speed and reliable multi-port networking.

• AMD Radeon RX Vega 6 Graphics: Supports DP and HD display output for local management, display terminals, and multimedia applications.

• Up to 32GB DDR4 Memory: Supports DDR4 SO-DIMM memory with up to 32GB capacity and up to 2666MHz frequency.

• Flexible Storage: Supports 1 × SATA 6Gb/s and 1 × M.2 Key-B+M interface for high-speed SSDs and large-capacity storage.

• Rich Expansion Options: Includes mPCIe, M.2 Key-B, dual SIM slots, and 2 × J_COM headers for communication modules and industrial peripherals.

• Industrial I/O: Provides RJ45 COM, USB 3.2, USB 2.0, front panel connector, power button, and reset button for easy deployment and maintenance.

• Active Cooling Design: Equipped with an intelligent chassis fan for sustained workloads and demanding operating environments.

Core Specifications

• Model: G31F-1140N4L

• Processor: AMD Ryzen Embedded R2314

• Socket: FP5

• Graphics: AMD Radeon RX Vega 6

• Memory: DDR4 SO-DIMM, up to 32GB, up to 2666MHz

• Network: 4 × 2.5GbE RJ45, Intel I226V controllers

• Storage: 1 × SATA 6Gb/s, 1 × M.2 Key-B+M

• Expansion: 1 × mPCIe, 1 × M.2 Key-B

• Display: 1 × HD, 1 × DP

• USB: 2 × USB-A 3.2, 4 × USB-A 2.0

• Communication: 1 × RJ45 COM, 2 × J_COM

• SIM: 2 × SIM card slots

• Antenna Holes: 2 × reserved

• Cooling Method: Active cooling with intelligent chassis fan

• Power Input: DC 12V 7A or higher

• Chassis Size: 178 × 126 × 56 mm

• Device Weight: Approx. 1.25 KG; package weight approx. 1.95 KG including accessories

• Operating Temperature: 0°C to 60°C

• Operating Humidity: 5% to 90% relative humidity, non-condensing

Application Scenarios

• Edge computing devices

• Cybersecurity appliances

• Industrial gateways

• Industrial control automation

• Virtualization platforms

• High-bandwidth multi-port data processing

• Server rooms, industrial sites, and high-temperature operating environments
