H14 13620H 4L

The H14 13620H 4L is a compact high-performance fanless embedded industrial computer powered by Intel 12th/13th Gen processors.  It integrates 4 × 2.5GbE RJ45 ports, dual-channel DDR5 SO-DIMM memory, M.2 Key-M 2280 high-speed storage,  SATA 3.0, PCIe x8, M.2 Key-B 3052, M.2 Key-E 2230, and SIM card expansion. With a rugged metal enclosure  and passive cooling design, it delivers quiet, reliable operation for cybersecurity appliances, edge computing,  industrial automation, virtualization platforms, digital signage, and compact server applications.

Core Specifications

• Model: H14 13620H 4L

• Processor Platform: Intel 13th Gen Processors

• Socket: FCBGA1744

• Graphics: Intel UHD Graphics

• Memory: 2 × DDR5 SO-DIMM, up to 96GB, up to 4800 MT/s

• Network: 4 × 2.5GbE RJ45, Intel I226V controllers

• Storage: 1 × SATA 3.0, 1 × M.2 Key-M 2280

• Expansion: 1 × PCIe x8, 1 × M.2 Key-B 3052, 1 × M.2 Key-E 2230

• Display: 1 × DP, 1 × HD

• USB: 2 × USB-A 3.0, 2 × USB-A 2.0, 1 × USB-C

• Serial Port: 1 × RJ45 COM RS232, 1 × COM expansion header

• Other Interfaces: 1 × SIM card slot, 1 × F_USB2.0, 1 × J_GPIO, 1 × J_TPM, 2 × reserved antenna holes

• Cooling Method: Passive cooling, fanless design, airflow recommended

• Power Input: DC 12V 7A or higher

• Chassis Size: 150 × 143 × 84 mm

• Device Weight: Approx. 1.90 KG; package weight approx. 2.60 KG including accessories

• Operating Temperature: 0°C to 50°C

• Operating Humidity: 5% to 90% relative humidity, non-condensing

Application Scenarios

• Cybersecurity appliances

• Edge computing devices

• Industrial automation control

• Virtualization platforms

• Digital signage systems

• Compact server applications

• Multi-port data processing and industrial network deployments
